EMX

EMX is built on RoboSense’s advanced digital automotive-grade front LiDAR platform—the EM Platform. It delivers real 192-beam and 2.88 million pts/s of high-definition point clouds, with a maximum frame rate of 20Hz, a detection range of up to 300 meters, and a wide horizontal FOV of 140°.

The intelligent "Gaze" function has been upgraded, with horizontal angular resolution improved by up to 6x, and the dynamic adjustment range significantly expanded. The EMX is customizable to meet the intelligent driving needs of various vehicle models.

192-Beam

High-beam

0.08°×0.10°

Global Angular Resolution (H × V)

20Hz

Ultra-high frame rate

300m

Longest ranging

2.88 Million pts/s

Ultra-high point rate

SPAD+VCSEL

Digital architecture

"Gaze" Function

Intelligent

120×80×30 (mm)

Compact Design (L × W × H)

192-Beam

High-beam

20Hz

Ultra-high frame rate

2.88 Million pts/s

Ultra-high point rate

"Gaze" Function

Intelligent

0.08°×0.10°

Global Angular Resolution (H × V)

300m

Longest ranging

SPAD+VCSEL

Digital architecture

120×80×30 (mm)

Compact Design (L × W × H)

Accurate Detection of Distant Objects

Black Car
Clearly detects a black car within 200m, enabling emergency avoidance or braking at speeds up to 160km/h.
Traffic Cone
Precisely identifies traffic cones within 200m, allowing emergency avoidance or braking at speeds up to 160km/h.
High-Speed Projectile
Accurately detects carton (30×17cm) within 120m, enabling emergency avoidance or braking at speeds up to 121km/h.
Black Tire
Accurately detects a stray tire within 80m, supporting emergency avoidance or braking at speeds up to 96km/h.

20Hz High Frame Rate: Low Latency & Quick Response

Leveraging RoboSense’s proprietary scanning technology and a control algorithm perfectly matched to the scanner’s dynamic characteristics, the EMX achieves a scanning frame rate of up to 20 Hz—twice the industry mainstream. With response latency cut by half, it provides intelligent driving and active safety systems with more time to react to sudden scenarios such as high-speed projectiles and cut-ins.

Exclusive Core Technology for All-Condition Adaptability

With the support of EM Platform’s leading exclusive technologies, EMX also features advanced capabilities such as high anti-expansion suppression, noise point reduction caused by rain, fog, and dust, as well as resistance to contamination and watermark occlusion. These technologies ensure the protection of autonomous driving systems in various complex scenarios.

Digital Architecture Accelerates Innovation in Autonomous Driving

Leveraging RoboSense's leading digital architecture, the EMX integrates digital SPAD-SoC and VCSEL chips, offering high detection sensitivity while preserving raw information. The digital LiDAR data is also more conducive to temporal and spatial synchronization with camera raw data, achieving optimal perception fusion and accelerating breakthroughs in autonomous driving systems. Meanwhile, with its highly integrated design based on advanced architecture, the EMX is the most compact automotive digital LiDAR on the market.
